Driving Type

Left / Right Hand Driving

Cabin

1880 Cabin ( Berth can be optional)

2080 Cabin ( Berth can be optional)

Engine

Power

102/120HP

140/160HP

Emission

Diesel EURO II, IV, V

Transmission

MANUAL, 5F, 6F

Steering

hydraulic steering with power assistance

Axle

Design and produce by SINOTRUK

Front/ Rear Axle

2.4+7.2

3.6+10.5

Wheelbase

3360/3800

4500/4700

Oil tank

120L

Tyres

7.00R16/7.50R16

8.25R20/9.0R20

Suction sewage tank

Capacity

3-5 m³

6-8m³

Material

Carbon steel/stainless steel

Suction depth m

6

Charge time min

3-5

Discharge time min

2-3

Charge hose diameter mm

100

Pump

Model

Jurop PN84

rated power   Kw

4

Rated speed r/min

500

Exhaust rate m3/min

1

Max vacuum Mpa

-0.092
