Driving Type

Left / Right Hand Driving

Cabin

1880 /2080 Cabin

Engine

Power

116/120 HP

140/160HP

Emission

Diesel EURO II, IV, V

Transmission

MANUAL 6F

Steering

hydraulic steering with power assistance

Frame

Reinforced frame

Front/ Rear Axle

2.7+7.2

3.2+8

Wheelbase

3360mm

4200mm

Oil tank

120L

Tyres

8.25R16/R20

Capacity

6m³

6-8m³

Volume of filler

0.9m³

Time of one filling cycle

25s

Time of discharge

45s

Lifting time of filler

8-10s

Pressure of hydraulic system

18MPa

Hydraulic system control

Mechanical (electric or manual )

Cylinder

Double-acting piston

Oil pump

Double gear pump

Valve

Multi-valve

Hydraulic tank capacity

150L

Time for lifting the bucket

≥40

Time for lifting the dump bucket

≥40

Diameter of oil cylinder

125mm

Maximum swing angle of the swing arm

118°

Maximum angle of dumping for self-discharging

86°

Swing radius of the swing arm

2700(mm)
