Driving Type

Left / Right Hand Driving

Cabin

1880 Cabin ( Berth can be optional)

2080 Cabin ( Berth can be optional)

Engine

Power

85-116HP

120HP

140-160HP

Emission

Diesel EURO II, IV, V

Transmission

MANUAL, 5F, 6F

Steering

hydraulic steering with power assistance

Frame

Reinforced frame

Front/ Rear Axle

2.0+4.2

2.4+7.2

3.6+10.5

Wheelbase

3360

3800/4200/4500

4700/5200

Oil tank

120L

Tyres

7.00R16

7.50R16/8.25R16

8.25R20/9.0R20

Water tanker

Capacity

1-5 m³

6-10m³

11-15 m³

Material

Carbon steel/stainless steel

Pump power

4.5kw

11.7kw

22.5kw

Spraying system

Front spraying

Rear spraying

Rear high pressure gun

Operating speed

5-10km/h

Water flow rate

60m³/h

Spraying width

≥14-18m

Pump head

≥26m
